HCB10-C Solarlink Inverter System

Category|Inverter

Spec.

  • Max. open voltage

    1000V

  • Indi. rated current

    12A

  • FUSE rated current

    20A

  • Rated voltage(STC)

    830V

  • Operating temperature

    -20˚C ~ 40˚C

  • Cooling method

    Natural air cooling

  • Enclosure IP

    IP65

  • Dimensions
    (W x D x H mm)

    600 X 210 X 440

  • Input Channel

    10CH

  • Rated output current

    120A

  • Monitoring device

    Not Installed

  • Material

    Steel

  • Storage temperature

    -20˚C ~ 60˚C

  • Alarm detection

    Fuse burn out(LED lamp)

  • Install type

    Wall type

  • Weight

    25kg

  • Certificated

    KS Certificate
